Do you know all the advantages of Coriolis mass flow meters?
Coriolis mass flow meter It is a flow measuring device that uses a direct measurement method of mass flow rate. It can directly measure the mass flow rate of fluids in a pipeline with high accuracy, and it has high stability, good reliability, a large measurement range, and is suitable for high-viscosity fluids and high-density gases. As a high-precision flow measurement device based on the Coriolis force principle, it demonstrates significant technological advantages in industrial process control and measurement fields due to its unique measurement mechanism and structural design.
The measurement system of a Coriolis mass flow meter mainly consists of an elastic measuring tube, an excitation unit, a vibration pickup unit, and a closed-loop self-excited amplifier circuit. Its working principle is as follows: the excitation unit drives the measuring tube into a resonant state, forming a stable "bending main vibration"; when the fluid flows through the vibrating measuring tube, a "torsional sub-vibration" proportional to the mass flow rate is generated due to the Coriolis force; by detecting the composite vibration signal through the vibration pickup unit and processing it through the circuit, the fluid mass flow rate value can be directly obtained.
Advantages of Coriolis mass flow meters:
1) Coriolis mass flow meters can meet the needs of most industries in terms of corrosion resistance, fouling resistance, explosion-proof performance, and wear resistance, and can measure a variety of media, such as oil products, chemical media, papermaking black liquor, pulp, gases, fluids containing solid particles, and high-viscosity substances.
2) There are no obstacles inside the pipeline, and there are no moving parts, reducing the risk of failure due to fluid erosion or component wear, while facilitating cleaning, daily maintenance, and maintenance operations, helping to extend the service life of the equipment.
3) The installation process is relatively simple, and the inlet and outlet directions of the sensor tubes of different sizes can be adjusted according to the on-site needs, making it convenient to use. Compared with some flow meters, its requirements for the configuration of inlet and outlet straight pipe sections are lower, which can reduce the limitations of installation space to a certain extent.
4) In the measurement scenario of multiphase fluids, Coriolis mass flow meters show good adaptability and can obtain relevant data relatively stably.
