ACU20FCH-LM Dimension Drawing
Product Center
ACU20FCH
The ACU20FCH series high-temperature steam flow controller/flowmeter utilizes a unique sensor and control valve to achieve precise measurement and control of steam.
Category:
Product attachment:
Product Description
- Product Description
-
I. Product Overview
◆ Quickly and accurately measures the volumetric or mass flow rate of process gases, liquids, or vapors
◆ Utilizes custom-designed high-speed proportional control valves for precise regulation of media volumetric or mass flow rates
◆ When measuring liquids, the uniquely designed vent hole allows air to be easily released.
◆ Setpoints and PID valve adjustments via the touch-enabled display, with open analog input/output and RS-485 digital communication capabilities.
◆ No movable components or heating elements inside; passes vibration tests and is insensitive to installation orientation.
◆ Utilizing internally compensated laminar flow differential pressure technology ensures that the fluid maintains laminar flow even at high flow rates.
◆Offering comprehensive user support, including technical consultations, fast equipment calibration services, and a conditional lifetime warranty.
II. Product Applications
The ACU20FCH series high-temperature mass flow meters/controllers are widely used across various industries, including process manufacturing, food analysis, and analytical testing and measurement applications.
Multi-variable measurement and a 50:1 adjustable range allow a single ACU20FCH high-temperature mass flow meter/controller to replace the functionality of multiple devices. With an accuracy of 0.5%, repeatability of 0.5%, and a control response time of less than 200 milliseconds, this ensures reliable operation for process gases, liquids, and vapors.
3. Technical Specifications
Series ACU20FCH Model LC LM MC MM BC BM Measurement range Gases: 0–(2, 5, 10…1000) SCCM, 0–(1, 5, 10…30) SLM Gas: 0–(30, 40, 50...300) SLM Gas: 0–(300, 400, 500...3000) SLM Liquid: 0–(2, 5, 10...500) SCCM Liquids: 0–(500, 600…1000) SCCM, 0–(1, 2, 3…10) SLM Liquid: 0-(1, 2, 30...10) SLM Steam: 0–(2, 5, 10...1000) SCCM, 0–(1, 2, 3...10) SLM 0 - (10, 20, 30...100) SLM 0 - (100, 150, 200...500) SLM Accuracy ±0.5% of F.S. Repetitiveness ±0.5% of F.S. Zero-point drift & Full-scale drift 0.02% F.S./°C/Atm Work differential pressure 0.1–0.5 MPa (specified upon order) Measurement range ratio 50:1 100:1 50:1 100:1 50:1 100:1 Typical Response Time 200 milliseconds (adjustable) Analog quantity 0–5V, 4–20mA Digital quantity RS232/485, MODBUS Protocol Power supply 24VDC Work stress <1 MPa Electrical connection DB9 port Protection Level IP40 Leak rate 1 × 10⁻⁹ Pa·m³/s Valve Valve remains closed / Valve remains closed / Valve remains closed / Base material Stainless steel Sealing material Fluororubber, nitrile rubber, EPDM, perfluoroether Surface Thread G3/8 internal thread G1/2 internal thread Connector Crimping sleeves, pagodas, quick-connect fittings, VCR connectors, flanges, and more Note: Product appearance and dimensions may vary depending on the medium and flow rate being measured.
4. Product Dimension Diagram
ACU20FCH-MC Dimension Drawing
ACU20FCH-MM Dimension Drawing
ACU20FCH-BC Dimension Drawing
