ACU10L-LC Dimensions
Product Center
ACU10L
The ACU10L series digital liquid flow controller/flow meter enables fast and accurate measurement of the volumetric/mass flow rate of process liquids; the ACU10LC series liquid flow controller uses a customized high-speed proportional control valve to accurately control the volumetric/mass flow rate of liquids.
Category:
Product attachment:
Product Description
- Product Description
-
I. Product Overview
◆ Quickly and accurately measures the volumetric flow/mass flow of process liquids
◆ Employs a customized high-speed proportional control valve for precise control of liquid volumetric flow/mass flow
◆ Features a unique vent for easy air purging
◆ Integrated multi-functional digital display allows users to control setpoints and PID valve adjustments via screen buttons, while also providing analog input/output and RS-485 digital communication
◆ No moving parts or heating elements inside; passes vibration tests and is insensitive to mounting orientation
◆ Uses internal compensation laminar flow differential pressure technology, ensuring laminar flow even at high flow rates
◆ Provides comprehensive user support, including technical consultation, quick device calibration service, and conditional lifetime warranty
II. Product Applications
The ACU10L series digital liquid flow controllers/flow meters are widely used in various industries, such as: process manufacturing, food analysis, analytical testing and measurement, etc.
Multi-variable measurement and a 50:1 adjustable range ratio allow a single ACU10L liquid flow controller/flow meter to replace multiple devices. Accuracy of 1%, repeatability of 1%, and a control response time of less than 200 milliseconds ensure normal operation of the process liquid.
III. Technical Parameters
Series ACU10L Model LC LM MC MM BC BM Range 0-（2,5,10...1000）SCCM 0-（1,2,3...5)SLM 0-（5,6,10...20)SLM Accuracy ±1.0%F.S Repeatability ±1%F.S Zero Drift & Full Scale Drift 0.02% F.S/ ºC/Atm Operating Differential Pressure 0.1~0.5MPa (specified at time of order) Turn Down Ratio 50：1 100：1 50：1 100：1 50：1 100：1 Typical Response Time 200 milliseconds (adjustable) Analog 0～5V、4～20mA Digital RS232/485，MODBUS protocol Power Supply 24VDC Operating Temperature +10~+50℃ Operating Pressure Drop <0.01Mpa Maximum Operating Pressure 1MPa Electrical Connection DB15 pin Protection Level IP40 Leak Rate 1×10-9Pa m³/S Valve Normally Closed Valve / Normally Closed Valve / Normally Closed Valve / Base Material Stainless Steel Seal Material Viton, Nitrile Rubber, EPDM, Perfluoroelastomer Body Thread G3/8 inner thread G1/2 inner thread Connector Compression fitting, Pagoda, Quick-connect, VCR, Flange, etc. IV. Product Dimensions
ACU10L-MC Dimensions
ACU10L-BC Dimensions
V. Optional Matching Monitoring and Control Software (Additional charges apply)
Mass Flow Monitoring and Control System V5.0
