ACU20FDL
The ACU20FDL liquid mass flow controller consists of components such as a mass flow sensor, a flow control valve, and an amplifier control circuit. It is made using the heat transfer distribution effect that changes the temperature distribution of the measuring capillary wall by the heat transfer of the flowing fluid. A customized high-speed proportional control valve is used to precisely control the liquid volume flow/mass flow.
Category:
Product attachment:
Product Description
- Product Description
-
I. Product Overview
◆ Thermal principle, higher accuracy, faster response, with network port
◆ Tubular flow distribution, not easy to block
◆ Suitable for various low-pressure and high-pressure pipelines
◆ Short preheating time, small zero drift, high reliability
◆ Analog input/output can be used to control and display flow rate with secondary instruments or flow computers
The ACU20FDL high-precision liquid mass flow meter/flow controller uses the principle of calorimetry of the temperature difference before and after capillary heat transfer to measure the mass flow rate of gas, which is not affected by temperature and pressure. The flow signal measured by the sensor is amplified and then compared with the set voltage. The obtained difference is used to drive the control regulating valve, and the closed-loop control of the flow rate through the channel makes it equal to the set flow rate.
II. Product Applications
Semiconductor Solar energy Industrial manufacturing Petrochemical Coal metallurgy Environmental protection Various instrument analysis III. Product Parameters
Product Model ACU20FDL-L Measurement Range 2g/h～1000g/h Measurement and Control Range Flow meter measurement range ratio 100:1, controller measurement range ratio 50:1 Accuracy ±0.5%F.S Linearity ±0.5%F.S Repeatability ±0.2%F.S Response Time Flow meter: <0.1s Flow controller: <0.2s Digital RS232/485, MODBUS protocol Analog 0～5V、4-20mA、1～5V Power Supply ±15VDC，24VDC Operating Temperature 0～50℃ Operating Pressure Operating pressure drop: <0.01Mpa Maximum Pressure Resistance 3MPa/10MPa Electrical Connection DB9 port Leakage Rate 1×10-9Pa m3/S Temperature Coefficient ±0.025%F.S/℃ Base Material Stainless steel Sealing Material Viton, chloroprene rubber, nitrile rubber Connector φ3，φ6，1/8"，1/4" IV. Product Dimensions
V. Optional Matching Measurement and Control Software (Additional Charge Applies)
Mass Flow Measurement and Control System V5.0
