ACU20FD-XS

The ACU20FD-XS intelligent flow display controller can provide operating power, flow setting (manual control), and flow display for analog and digital mass flow controllers. The flow display can be directly used with all products manufactured by our company. It is easy to use and can be installed either embedded or desktop, with an exquisite and beautiful appearance.

Category:

Display and Control System

Product attachment:

Get a quote

I. Product Overview

◆Provides operating power for mass flow controllers or flow meters

◆Manual operation control for flow setting

◆Gas flow display

◆Can be used with other models of mass flow controllers

The ACU20FD-XS intelligent flow display control instrument is generally used with a flow controller or flow meter, providing 24V or ±15V power supply. The supply voltage should be specified before the product leaves the factory. The flow display instrument's 2.4-inch color screen clearly and intuitively displays key information such as flow rate, flow rate unit, medium type, set value, and valve status. The set value flow setting can be achieved through four methods: analog, digital, knob, and touch panel: 1. Digital setting via RS485 interface, protocol is Modbus RTU; 2. Analog signal via 0~5V or 4~20mA setting; 3. Setting via touch panel; 4. Setting via knob. The flow display instrument is compatible with all flow meters or flow controllers produced by our company and can be used directly.

II. Technical Parameters

1	Power Input	100~240VAC，50~60Hz
2	Power Output	24V, 1A 15V, 1A -15, 1A (Specific to MFC customization)
3	Display Method	2.4-inch high-definition color screen
4	Control Channel	1-way MFC
5	Operating Temperature	0~50℃
6	Digital	RS485 MODBUS protocol
7	Analog	DC 0~5V，4~20mA selectable
8	Aperture Size	92x92mm
